Tribology and Materials | Volume 3 | Issue 1 | 2024 | 35-43
|
https://doi.org/10.46793/tribomat.2024.005
|
|
Mechanical properties of laminate materials based on polylactic acid and polyvinyl chloride meshes as reinforcement
Miloš Vorkapić
1,
Danica M. Bajić2,
Marija Baltić3,
Dušan Nešić1,
Ivana Mladenović1
1 University of Belgrade, Institute of Chemistry, Technology and Metallurgy, Belgrade, Serbia
2 Military Technical Institute, Belgrade, Serbia
3 University of Belgrade, Faculty of Mechanical Engineering, Belgrade, Serbia
Abstract: The 3D printing parameters are known to have a
significant impact on manufactured parts, and the layered morphology of
these parts makes mechanical design analysis for engineering
applications difficult. In this work, the tensile strengths and
microhardness of 3D printed polylactic acid (PLA) specimens with
different orientations and numbers of individual layers of mesh material
(polyvinyl chloride – PVC) were investigated as a laminate composite.
Composite specimens were obtained using 3D printing via fused deposition
modelling (FDM). Moreover, the influence of printing parameters (i.e.
infill density and layer height) and the number and orientation of
reinforced meshes on the mechanical response was investigated. Fracture
strength of PLA/PVC laminate composites ranges from 31.30 MPa (3 PVC
mesh layers; mesh height position: 25 %│50 %│75 %; infill density:
60 %; PVC mesh orientation: 90°│45°│90°; layer height: 0.2 mm) to
18.62 MPa (without PVC mesh; infill density: 30 %; layer height: 0.1 mm)
demonstrating a significant impact of the number of the PVC mesh layers,
infill density of PLA and layer height on the final mechanical
parameters of printing PLA/PVC elements. The surface hardness at the
micro load level showed that the number of reinforcement layers affects
the microhardness value, as well as material filling and mesh
orientation. The specimen with the following parameters gave the best
results: layer height: 0.2 mm; 3 PVC mesh layers; infill density: 60 %;
PVC mesh orientation: 90°│45°│90°. The average hardness values for
one layer and three layers of mesh were in accordance with tensile test
results.
Keywords:
composite, PLA, PVC, laminate, tensile test, microhardness.
Received: 20-01-2024, Revised: 28-03-2024, Accepted: 30-03-2024
